UCC3804NG4

Images are for reference only
See Product Specifications

Mouser No:

595-UCC3804NG4

Mfr. No:

UCC3804NG4

Mfr.:

Texas Instruments
Texas Instruments

Description:

Switching Controllers Low-Power BiCMOS Current-Mode PWM

Lifecycle:

Obsolete

Datasheet:

UCC3804NG4 Datasheet

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

Shipping Alert:

Mouser does not presently sell this product in your region.

Availability

Stock:: An unexpected error occurred. Please try again later.

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	Switching Controllers
Delivery Restrictions:	Mouser does not presently sell this product in your region.
RoHS:
Topology:	Boost, Buck, Flyback, Forward
Number of Outputs:	1 Output
Switching Frequency:	1 MHz
Duty Cycle - Max:	50 %
Output Voltage:	5 V
Output Current:	1 A
Minimum Operating Temperature:	0 C
Maximum Operating Temperature:	+ 70 C
Mounting Style:	Through Hole
Package/Case:	PDIP-8
Packaging:	Tube
Brand:	Texas Instruments
Fall Time:	44 ns
Product Type:	Switching Controllers
Rise Time:	41 ns
Series:	UCC3804
Factory Pack Quantity:	50
Subcategory:	PMIC - Power Management ICs
Type:	Current Mode PWM Controllers
Unit Weight:	523.200 mg
