TLE2021IP

Texas Instruments
595-TLE2021IP
TLE2021IP

Mfr.:

Description:
Precision Amplifiers HS Low Power

Datasheet:
ECAD Model:
Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

In Stock: 190

Stock:
190 Can Dispatch Immediately
Factory Lead Time:
6 Weeks Estimated factory production time for quantities greater than shown.
Minimum: 1   Multiples: 1
Unit Price:
£-.--
Ext. Price:
£-.--
Est. Tariff:

Pricing (GBP)

Qty. Unit Price
Ext. Price
£1.98 £1.98
£1.48 £14.80
£1.35 £67.50
£1.20 £120.00
£1.14 £285.00
£1.10 £550.00
£1.07 £1,070.00
£1.04 £2,600.00
£1.01 £5,050.00

Product Attribute Attribute Value Select Attribute
Texas Instruments
Product Category: Precision Amplifiers
RoHS:
1 Channel
2 MHz
650 mV/us
120 uV
25 nA
40 V
4 V
240 uA
20 mA
110 dB
19 nV/sqrt Hz
PDIP-8
Through Hole
No Shutdown
- 40 C
+ 85 C
TLE2021
Tube
Amplifier Type: Low Offset Amplifier
Brand: Texas Instruments
Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V
Height: 4.57 mm
In - Input Noise Current Density: 0.09 pA/sqrt Hz
Input Type: Rail-to-Rail
Length: 9.81 mm
Maximum Dual Supply Voltage: +/- 20 V
Minimum Dual Supply Voltage: +/- 2 V
Operating Supply Voltage: 4 V to 40 V, +/- 2 V to +/- 20 V
Pd - Power Dissipation: 1 W
Product: Precision Amplifiers
Product Type: Precision Amplifiers
Factory Pack Quantity: 50
Subcategory: Amplifier ICs
Supply Type: Single, Dual
Technology: BiCOM
Voltage Gain dB: 123.52 dB
Width: 6.35 mm
Unit Weight: 440.400 mg
Products found:
To show similar products, select at least one checkbox
Select at least one checkbox above to show similar products in this category.
Attributes selected: 0

This functionality requires JavaScript to be enabled.

CNHTS:
8542339000
CAHTS:
8542330000
USHTS:
8542330001
JPHTS:
8542330996
KRHTS:
8532331000
MXHTS:
85423999
ECCN:
EAR99
