MSP430G2212IPW20

Name: Texas Instruments MSP430G2212IPW20
Brand: Texas Instruments
SKU: 595-MSP430G2212IPW20
Price: 0.7 GBP
Availability: OutOfStock

Images are for reference only
See Product Specifications

Mouser No:

595-MSP430G2212IPW20

Mfr. No:

MSP430G2212IPW20

Mfr.:

Texas Instruments
Texas Instruments

Description:

16-bit Microcontrollers - MCU Mixed Signal Micro c ontroller A 595-SP430G2212IPW20R

Datasheet:

MSP430G2212IPW20 Datasheet

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Texas Instruments MSP430G2212IPW20

Availability

Stock:: Non-Stocked

An unexpected error occurred. Please try again later.
Factory Lead Time:: 18 Weeks Estimated factory production time.

Enter Quantity:

Minimum: 1050 Multiples: 70

Unit Price:

£-.--

Ext. Price:

£-.--

Est. Tariff:

This Product Ships FREE

Pricing (GBP)

Qty.	Unit Price	Ext. Price
	£0.704	£739.20
	£0.679	£1,711.08
	£0.664	£3,346.56

Alternative Packaging

Mfr. Part No.:

MSP430G2212IPW20R

Packaging:

Reel, Cut Tape, MouseReel

Availability:

In Stock

Price:

£1.16

Min:

Similar Product

Mfr.:

Texas Instruments

Mfr. No:

MSP430G2212IPW20R

Description:

16-bit Microcontrollers - MCU Mixed Signal Micro c ontroller A 595-MSP430G2212IPW20

Compare With Current Part

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	16-bit Microcontrollers - MCU
RoHS:
Core:	MSP430
Program Memory Size:	2 kB
Data RAM Size:	256 B
Package/Case:	TSSOP-20
Maximum Clock Frequency:	16 MHz
Number of I/Os:	16 I/O
Supply Voltage - Min:	1.8 V
Supply Voltage - Max:	3.6 V
Mounting Style:	SMD/SMT
Data Bus Width:	16 bit
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 85 C
Series:	MSP430G2212
Packaging:	Tube
Brand:	Texas Instruments
Data RAM Type:	SRAM
Interface Type:	I2C, SPI
Number of Timers/Counters:	1 Timer
Processor Series:	2 Series
Product Type:	16-bit Microcontrollers - MCU
Program Memory Type:	Flash
Factory Pack Quantity:	70
Subcategory:	Microcontrollers - MCU
Tradename:	MSP430
Watchdog Timers:	No Watchdog Timer
Unit Weight:	191 mg

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Datasheet

MSP430G2212IPW20 Datasheet

Images

Models

MSP430G2212IPW20 Symbol & Footprint by SnapMagic

PCN

Product Catalogs

This functionality requires JavaScript to be enabled.

CNHTS:: 8542319090
CAHTS:: 8542310000
USHTS:: 8542310020
JPHTS:: 854231032
KRHTS:: 8542311000
TARIC:: 8542319000
MXHTS:: 8542310302
ECCN:: EAR99

MSP430G2x Microcontrollers (MCUs)

Texas Instruments MSP430G2x Microcontrollers (MCUs) are from the MSP ultra-low-power MCU series. These microcontrollers offer the low power and performance of a 16-bit MSP microcontroller with a feature set targeted at cost-sensitive applications. Select Texas Instruments MSP430G2x devices that can operate at extended temperatures from -55°C to 150°C.

Processors

Texas Instruments Processors provide a comprehensive portfolio, proven software, and worldwide support, enabling industry-leading automotive and industrial solutions. TI is dedicated to advancing and optimizing today’s processors to meet tomorrow’s intelligence, performance, and cost requirements in automotive and industrial applications. Scalable hardware and software platforms with common code allow designers to seamlessly reuse and migrate across devices to protect future investment.

Texas Instruments Power for Processors

Texas Instruments SIMPLE SWITCHER® nano modules and regulators can be paired with TI high-performance processors to create the ideal power solution for your space-constrained application. SIMPLE SWITCHER nano modules and regulators make power design easy for MSP430™, C2000™, and Stellaris® microcontrollers (MCUs) as well as Sitara™ microprocessors (MPUs) and C6000™ digital signal processors (DSPs).
Learn More

MSP430™ Microcontrollers

Texas Instruments MSP430™ Family of Ultra-Low Power Microcontrollers (MCUs) includes several devices featuring different sets of peripherals for various applications. TI's MSP430 features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that attribute to maximum code efficiency. The digitally controlled oscillator allows wakeup from a low-power mode to active mode in less than 6µS. The MSP430 16-bit microcontroller platform of ultra-low power RISC mixed-signal microprocessors from Texas Instruments provides the ultimate solution for a wide range of low power and portable applications. TI provides robust design support for the MSP430 16-bit MCU, including technical documents, training, tools, and software.
