LM2735YQMFX/NOPB

Images are for reference only
See Product Specifications

Mouser No:

926-LM2735YQMFX/NOPB

Mfr. No:

LM2735YQMFX/NOPB

Mfr.:

Texas Instruments

Lifecycle:

Obsolete

Datasheet:

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

Shipping Alert:

Mouser does not presently sell this product in your region.

Mfr. Part No.:

Packaging:

Reel, Cut Tape, MouseReel

Availability:

In Stock

Price:

£2.14

Min:

1

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	Switching Voltage Regulators
Delivery Restrictions:	Mouser does not presently sell this product in your region.
RoHS:
Mounting Style:	SMD/SMT
Package/Case:	SOT-23-5
Topology:	Boost
Output Voltage:	3 V to 24 V
Output Current:	2.1 A
Number of Outputs:	1 Output
Input Voltage - Min:	2.7 V
Input Voltage - Max:	5.5 V
Switching Frequency:	520 kHz
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 125 C
Series:	LM2735-Q1
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Brand:	Texas Instruments
Operating Supply Current:	7 mA
Product Type:	Switching Voltage Regulators
Factory Pack Quantity:	3000
Subcategory:	PMIC - Power Management ICs
Type:	Step Up
Unit Weight:	6.300 mg
