DAC7621E/1K

Images are for reference only
See Product Specifications

Mouser No:

595-DAC7621E/1K

Mfr. No:

DAC7621E/1K

Mfr.:

Texas Instruments
Texas Instruments

Lifecycle:

Obsolete

Datasheet:

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

Shipping Alert:

Mouser does not presently sell this product in your region.

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	Digital to Analog Converters - DAC
Delivery Restrictions:	Mouser does not presently sell this product in your region.
RoHS:
Series:	DAC7621
Resolution:	12 bit
Sampling Rate:	143 kS/s
Number of Channels:	1 Channel
Settling Time:	10 us
Interface Type:	Parallel
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 85 C
Mounting Style:	SMD/SMT
Package/Case:	SSOP-20
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Architecture:	R-2R
Brand:	Texas Instruments
Height:	1.95 mm
Moisture Sensitive:	Yes
Number of Converters:	1 Converter
Operating Supply Voltage:	5 V
Power Consumption:	2.5 mW
Product Type:	DACs - Digital to Analog Converters
Factory Pack Quantity:	1000
Subcategory:	Data Converter ICs
Supply Voltage - Max:	5.25 V
Supply Voltage - Min:	4.75 V
Type:	Precision
Unit Weight:	174.700 mg
